Enerpac® LPL602
send Send print Print

Enerpac® LPL602

Enerpac® LPL602 Load Return Lock Nut Low Height Single Acting Solid Plunger Hydraulic Cylinder, 68 ton Capacity, 4.13 in Bore, 1.97 in L Stroke, 4.94 in Retract, 3.78 in Dia Rod, 10150 psi Pressure

  • TIEPN: ENP LPL602
  • MPN: LPL602
  • UPC: 662005393534
  • Min. Order Qty: 1
  • Quantity Interval: 1
  • loading

Enerpac® Hydraulic Cylinder, Load Return Lock Nut Low Height Single Acting Solid Plunger, 68 ton, 4.13 in Bore, 1.97 in Stroke, 4.94 in Retract, Base Mount, 3/8-18 NPTF, 3.78 in Rod Dia, 10150 psi, Steel Housing, 5.51 in OD x 6.91 in H

Dimensions      :      5.51 in OD x 6.91 in H
Housing Material      :      Steel
Mounting Type      :      Base
Port Size      :      3/8-18 NPTF
Series      :      LPL
Type      :      Load Return Lock Nut Low Height Single Acting Solid Plunger
Capacity      :      68 ton
Bore Size      :      4.13 in
Stroke Length      :      1.97 in
Retract      :      4.94 in
Rod Diameter      :      3.78 in
Pressure Rating      :      10150 psi
  • Lock nut provides mechanical load holding for a safe work environment
  • Integrated tilt saddle allows for up to 5 deg of misalignment
  • Extreme low height for use in confined areas
  • 10% side load resistance of maximum capacity
  • Overflow port as stroke limiter to prevent plunger blow-out
  • Single acting, gravity return
