Proto® J1212MH-T500

Proto® TorquePlus™ J1212MH-T500 Combination Wrench, 12 mm, 6 Points, 15 deg Offset, 7-23/32 in OAL, Alloy Steel, Full Polished, ASME B107.100

  • TIEPN: PRO J1212MH-T500
  • MPN: J1212MH-T500
  • UPC: 662679087326
  • Min. Order Qty: 1
  • Quantity Interval: 1
  • loading

Proto® TorquePlus™ Combination Wrench, Measurement System: Metric, 12 mm Wrench Opening, 6 Points, 7-23/32 in Overall Length, 15 deg Offset, 1 in Open End Width, 19/64 in Open End Thickness, 47/64 in Box End Width, 11/32 in Box End Thickness, 15 deg Head, Specifications Met: ASME B107.100, 9/16 in Throat Depth, Alloy Steel, Full Polished

Box End Thickness      :      11/32 in
Box End Width      :      47/64 in
Head Angle      :      15 deg
Open End Thickness      :      19/64 in
Open End Width      :      1 in
Throat Depth      :      9/16 in
Measurement System      :      Metric
Wrench Opening      :      12 mm
Number of Points      :      6
Offset Angle      :      15 deg
Overall Length      :      7-23/32 in
Material      :      Alloy Steel
Finish/Coating      :      Full Polished
Specifications Met      :      ASME B107.100
  • Full polish finish provides corrosion resistance and easy to clean surfaces
  • 6-point box end allows for large wrench to fastener contact area which helps prevent rounding of the fastener
  • Anti-slip design (ASD) open end
  • Metric sizes 9 mm and smaller do not have ASD feature
  • Box ends incorporate the TorquePlus™ system
  • pdfCatalog https://assets.unilogcorp.com/2/ITEM/DOC/Proto_J1210_Catalog.pdf
