Streamlight® 69166

Streamlight® 69166 TLR-2® IR Rail Mount Tactical Light With IR Illuminator and Eye Safe IR Aiming Laser, IR LED Bulb, Aluminum/Engineering Polymer Laser Housing

  • TIEPN: SLI 69166
  • MPN: 69166
  • UPC: 080926691667
  • Min. Order Qty: 1
  • Quantity Interval: 1
  • loading

The TLR-2 IR eye safe is a light weight weapon-mounted tactical light for use with night vision equipment. The class 1 "Eye Safe" IR laser provides you with long range targeting while the IR LED gives you optimum illumination.

Streamlight® Tactical Light, Rail Mount, Series: TLR-2® IR, 3 VDC, IR LED Bulb, 20000 hr Average Life, CR123A Lithium Battery, 2 Batteries, Black, Aluminum/Engineering Polymer Laser Housing, IPX4 Enclosure, 3.39 x 1.47 x 1.83 in

Average Life      :      20000 hr
Battery Type      :      CR123A Lithium
Color      :      Black
Dimensions      :      3.39 x 1.47 x 1.83 in
Enclosure      :      IPX4
Number Of Batteries      :      2
Series      :      TLR-2® IR
Type      :      Rail Mount
Voltage Rating      :      3 VDC
Bulb Type      :      IR LED
Housing Material      :      Aluminum/Engineering Polymer Laser
  • Illumination sources high power IR LED: 850 nm, impervious to shock with a 20000 hr life time IR laser 850nm, class 1
  • IR LED total radiant flux greater than 125 mW
  • Runs 7.5 hrs using IR illuminator/IR laser simultaneously
  • Deep dish parabolic reflector produces a concentrated infrared beam with optimum peripheral illumination
  • Infrared laser 850 nm, class 1 eye-safe
  • Eye safe output power less than 0.8 mW, runs 45+ hrs in laser only mode
  • Provides long range targeting
  • Solid state current regulation for consistent illumination level
  • Three position mode selector switch (IR laser only, IR illuminator only, both)
  • Powered by two 3V CR123 lithium batteries (included) with 10-year storage life
  • 6000 series anodized machined aircraft aluminum body with high impact, chemically resistant engineering polymer laser housing
  • High temperature, shock mounted, impact resistant borofloat glass lens
  • One handed snap-on and tighten interface keeps hands away from muzzle when attaching/detaching
  • Mounts directly to weapons with glock style rails and to all MIL-STD-1913 (picatinny) rails
  • Highly accurate sight repeatability when remounting
  • Ambidextrous momentary/steady on-off switch
  • Operating temperature of -40 to 140 deg F
  • IPX4 water resistant
  • Lithium battery notice under TECH DOCS
  • pdfSpecification Sheet https://assets.unilogcorp.com/2/ITEM/DOC/Streamlight_69166_Specification_Sheet.pdf
