Bessey® TW28GRS30-12

Bessey® TW28GRS30-12 Welding Table Hold Down Clamp, 5000 N Holding, 300 mm H, Steel

  • TIEPN: BTN TW28GRS30-12
  • MPN: TW28GRS30-12
  • UPC: 788502202107
  • Min. Order Qty: 1
  • Quantity Interval: 1
  • loading

Bessey® welding table clamps designed for 28 mm matrix tables are available in a wide range of choices for different needs including variable throat depth versions and accessories to complement the clamps. The TW28 series from Bessey® offers clamping elements with two fixed throat depths of 4-3/4 in (120 mm) and 5-1/2 in and a clamping capacity of approx. 12 in (300 mm). For increased flexibility the TWV28 series adds 3 more clamps into the mix that have variable throat depth. The variable throat depth may be set to any distance that falls within the min-max range of the sliding arm. Both series are characterized by a tempered profiled rail and forged sliding arm for strength where you need it, as well as the option to choose between three handle variants. The versions with the high quality 2-component plastic handle and the T-bar have a smooth-running trapezoidal threaded spindle and replaceable pressure pads that require no tools to install. The lever handle variant has a positive locking ratchet mechanism for controlled, fast and vibration-proof clamping. There is also version with a gripping arm (TW28GRS) and a heavy duty version with T-handled spindle and heavy-duty MorPad. Many accessories are available, such as V-blocks, variable risers and assorted adapters that enable the use of toggle clamps and other machine-table clamps on matrix tables with 28 mm holes.

Bessey® Welding Table Hold Down Clamp, Series: TW28, 5000 N Holding Force, 300 mm Maximum Ram Height, Steel

Series      :      TW28
Holding Force      :      5000 N
Maximum Ram Height      :      300 mm
Material      :      Steel
  • The spindle is located on the outside for free access to the work area and to protect against welding spatter
  • Special, sturdy V-grooved pressure plate, ideal even for clamping round or square workpieces
  • Pivotable and infinitely adjustable in terms of height
  • Particularly suited to clamping with the tightest of space constraints, in narrow openings as well as for short projections
  • V-grooved pressure plate
  • 120 mm D throat
