Enerpac® Cordless Hydraulic Torque Wrench Pump Kit, 1/2 hp, 120 cu-in Tank, 15 cu-in/min, 10000 psi, 18.32 in Overall Length, 8.22 in Overall Width, 11.7 in Overall Height
| Horsepower |
: |
1/2 hp |
| Overall Height |
: |
11.7 in |
| Overall Length |
: |
18.32 in |
| Overall Width |
: |
8.22 in |
| Pressure Rating |
: |
10000 psi |
| Series |
: |
XCTW |
| Tank Capacity |
: |
120 cu-in |
| Flow Rate |
: |
15 cu-in/min |
- Portable battery pump for torque applications
- This portable pump is perfect for remote locations, sites that do not have access to power or where trip hazards are a concern
- The interactive pendant allows the user to set and clear pressure and operate in manual or auto cycle mode
- The pump has an easily accessible user adjustable valve for precise pressure control
- Ideal for maintenance bolting applications requiring portability and convenience
- Interactive pendant provides visual and vibratory feedback of pump operation
- Superior run time with 5 Ah, 28 V battery
- 20 ft detachable pendant control
- 4 in glycerin filled gauge for easy viewing
- Bladder reservoir allows pump to be used in any position
- High strength fiberglass reinforced composite housing provides superior durability in demanding job site environments
- Integrated handle and carrying strap for portability
- For use with the S1500X, W2000X, S3000X and W4000 XC cordless torque wrench pump
- Larger wrenches will work with the pump, battery run time and application speed will be impacted
- Fasteners torqued on one charge: 32 fasteners torqued with an S3000 torque wrench on a 2-3/8 in nut AF, 1-1/2 in stud at 4800 psi and 1500 ft-lb
- Fasteners torqued on one charge: 52 fasteners torqued with an W2000 torque wrench on a 2-3/8 in nut AF, 1-1/2 in stud at 5000 psi and 1500 ft-lb
- Batteries and charger not included
