Scotchlok™ 7100164149

Scotchlok™ 7100164149 Standard Terminal, 8 AWG Conductor, 1.06 in L, 0.175 in ID x 0.31 in L Brazed Barrel, ETP Copper, Red

  • TIEPN: 3MC 054007-02122-3
  • MPN: 7100164149
  • UPC: 054007021223
  • Min. Order Qty: 1
  • Quantity Interval: 1
  • loading

3M™ Scotchlok™ ring tongue terminal ensures an ideal fit while offering reliable and safe performance. The non insulated, brazed seam barrel has a beveled mouth that guides the wire into position, and it withstands a maximum temperature of 347 degrees F (175 degrees C). Electrolytic copper construction offers good conductivity and a tin plated finish resists corrosion.

Scotchlok™, 7100164149, Terminal, Standard, Non-Insulated Conductor, 8 AWG Conductor, 5/16 in Stud, 1.06 in Length, 0.175 in ID x 0.31 in L Brazed Barrel, 600 to 1000 VAC, 347 deg F, ETP Copper, Red, 0.59 in W x 0.05 in THK Dimensions

Conductor Type      :      Non-Insulated
Dimensions      :      0.59 in W x 0.05 in THK
Stud Size      :      5/16 in
Temperature Rating      :      347 deg F
Type      :      Standard
Voltage Rating      :      600 to 1000 VAC
Conductor Size      :      8 AWG
Length      :      1.06 in
Barrel Type      :      0.175 in ID x 0.31 in L Brazed
Material      :      ETP Copper
Color      :      Red
  • It cannot be removed unless mounting screw is removed
  • Crimp connection
  • Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
  • Funnel-designed, seamless brass sleeve offers easy insertion of wires
  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires
