Dynabrade® Vertical Depressed Center Wheel Grinder, Type 27 Gearless, Tool/Kit: Bare Tool, 7 in Wheel Dia, 5/8-11 Male, 8500 rpm, 2 hp, 84 scfm, 90 psi Air, 1/2 in NPT Air Inlet, Side/Rotational Exhaust Location, Safety-Lock Lever Throttle, 1/2 in ID Minimum Hose Size, 81 dB, 9-1/2 in L x 6-1/2 in H
| Air Inlet |
: |
1/2 in NPT |
| Dimensions |
: |
9-1/2 in L x 6-1/2 in H |
| Exhaust Location |
: |
Side/Rotational |
| Minimum Hose Size |
: |
1/2 in ID |
| Sound Level |
: |
81 dB |
| Speed |
: |
8500 rpm |
| Throttle Style |
: |
Safety-Lock Lever |
| Tool/Kit |
: |
Bare Tool |
| Type |
: |
Type 27 Gearless |
| Wheel Diameter |
: |
7 in |
| Arbor/Shank Size |
: |
5/8-11 Male |
| Horsepower |
: |
2 hp |
| Air Flow Rate |
: |
84 scfm |
| Air Pressure |
: |
90 psi |
- Governor controlled air motor maintains tool rpm under heavy load
- For peak performance, use of optional 95870 air hose 1/2 in (13 mm) Dia is recommended
- Model accepts optional type 27 reinforced depressed center wheels, 7 in (178 mm) Dia
- Wheel not included with tool
- Covers more area in less time
- Over speed shut-off feature ensures maximum operator safety
- Motor is gearless with less wearable parts, ensuring reduced maintenance and less down-time
- Insulated tool handle minimizes cold air transmission to the hand
- Handle position is adjustable for operator comfort
