Dynabrade® Cut-Off Wheel Tool, Central Vacuum Straight Line, Tool/Kit: Bare Tool, 3 in Wheel Dia, 20000 rpm, 37 scfm, 90 psi Air, 1/4 in NPT Air Inlet, Rear Load Exhaust Location, 79 dB, 10-5/16 in L x 5-1/4 in H
Air Inlet |
: |
1/4 in NPT |
Dimensions |
: |
10-5/16 in L x 5-1/4 in H |
Exhaust Location |
: |
Rear Load |
Sound Level |
: |
79 dB |
Type |
: |
Central Vacuum Straight Line |
Tool/Kit |
: |
Bare Tool |
Wheel Diameter |
: |
3 in |
Speed |
: |
20000 rpm |
Air Flow Rate |
: |
37 scfm |
Air Pressure |
: |
90 psi |
- Our air powered, 3 in Dia, straight-line, flush cut-off wheel tool is ideal for central vacuum systems
- Accepts optional 3 in (76 mm) Dia diamond cut-off wheels with 3/8 in (10 mm) Dia mandrel
- The unique shroud and flange design adds versatility
- This too has plenty of power, 0.7 hp, 20000 rpm, rear exhaust
- Non marring plastic flange protects work surface while cutting
- Adjustable cutting height, from flush to 5/8 in (16 mm) above work surface is achieved by inserting wheel mandrel deeper into collet
- Operating tool in horizontal position allows flush-cut trimming of edges
- An essential tool for boat builders, pool, spa and shower manufacturers and in composite industries
- Extended rear exhaust muffler for reduced sound levels
- Ideal for both vertical and horizontal operation
- A 3 in (76 mm) dia diamond wheel with integrated mandrel is required (sold separately)
- Tool has 1 in (25 mm) Dia vacuum port for central vacuum systems
- Speed of tool must not exceed maximum operating speed of accessory
- Never mount bonded grinding wheels
- Always wear eye, face and body protection
- Unique cutaway shroud design allows 1 in (25 mm) wheel depth exposure
- Non-marring plastic flange protects work surface while cutting
- Includes 94300 composite Dynaswivel®, enhancing operator comfort and control
- Safety-lock lever ideal for both vertical and horizontal operation
- 0.7 hp motor speed
